Onze motoren door de jaren heen…..

Laurens en Erik

Custom Build Motorcycle NL Bobbers

Yamaha Wildstar 1600

Harley-Davidson Road Glide Special

General information
Model Harley-Davidson Road Glide Special
Year 2020
Category Touring
Engine and transmission
Displacement 1868.0 ccm (113.99 cubic inches)
Engine type V2, four-stroke
Engine details Milwaukee-Eight® 114 engine
Power 100.0 HP (73.0 kW)) @ 5020 RPM
Torque 165.4 Nm (16.9 kgf-m or 122.0 ft.lbs) @ 3000 RPM
Compression 10.5:1
Bore x stroke 102.0 x 114.3 mm (4.0 x 4.5 inches)
Fuel system Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Fuel control Double Overhead Cams/Twin Cam (DOHC)
Lubrication system Dry sump
Cooling system Oil & air
Gearbox 6-speed
Transmission type Belt   (final drive)
Clutch Multi-plate with diaphragm spring in oil bath
Driveline Chain, 34/46 ratio primary drive
Fuel consumption 5.47 litres/100 km (18.3 km/l or 43.00 mpg)
Greenhouse gases 126.9 CO2 g/km. (CO2 – Carbon dioxide emission)
Exhaust system Black, 2-1-2 dual exhaust with tapered mufflers
Chassis, suspension, brakes and wheels
Rake (fork angle) 26.0°
Trail 173 mm (6.8 inches)
Front suspension Telescopic fork
Rear suspension Twin shocks
Front tire 130/60-B19
Rear tire 180/55-B18
Front brakes Double disc. ABS. 4-piston
Rear brakes Single disc. ABS. 4-piston
Wheels Gloss Black Prodigy
Physical measures and capacities
Dry weight 372.0 kg (820.1 pounds)
Weight incl. oil, gas, etc 388.0 kg (855.4 pounds)
Power/weight ratio 0.2688 HP/kg
Seat height 695 mm (27.4 inches) If adjustable, lowest setting.
Overall length 2430 mm (95.7 inches)
Ground clearance 140 mm (5.5 inches)
Wheelbase 1625 mm (64.0 inches)
Fuel capacity 22.71 litres (6.00 US gallons)
Oil capacity 3.80 litres (4.02 US quarts)
Other specifications
Color options White
Starter Electric
Instruments Fairing-mounted electronic speedometer with odometer; time-of-day clock on CD player/stereo; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-speed indicator light Tachometer with fuel, voltage, oil pressure and ambient air temperature gauges
Light High beam, running lights, front fender light, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system (optional), 6-speed, low fuel warning, cruise control (optional), ABS (optional)
Carrying capacity Saddle bags
Comments Small windshield. Cruise control. Alarm. Infotainment.

Suzuki TL1000S

Suzuki TL1000S
Capacity 996cc
Bore x Stroke 98x66mm
Engine layout 90-degree V-twin
Engine details Liquid-cooled, 8v, DOHC
Power 123bhp (91.7kW) @ 8,500rpm
Torque 76.3lb-ft (103.4Nm) @ 8,000rpm
Top speed 165mph (est)
Transmission 6-speed, chain
Average fuel consumption 42mpg
Tank size 17litres
Max range to empty (theoretical) 157miles
Reserve capacity 25miles (est)
Rider aids None
Frame Tubular aluminium trellis
Front suspension 43mm inverted telescopic forks
Front suspension adjustment Preload, compression and rebound damping
Rear suspension Spring with remote rotary damper
Rear suspension adjustment Preload, compression and rebound damping
Front brake 2 x 320mm discs, four-piston calipers
Rear brake 220mm disc, twin-piston caliper
Front tyre 120/70 – 17
Rear tyre 180/60 – 17
Rake/Trail 23.7º/94.5mm
Dimensions 2065mm x 715mm x 1175mm (LxWxH)
Wheelbase 1415mm
Ground clearance 140mm
Seat height 835mm
Kerb weight 211kg
